| Part No. | Size | std. packing |
|---|---|---|
| DUTUX MHE 1818 | 1/8″ X 1/8″ | 50 |
| DUTUX MHE 1814 | 1/8″ X 1/4″ | 50 |
| DUTUX MHE 18516 | 1/8″ X 5/16″ | 50 |
| DUTUX MHE 1838 | 1/8″ X 3/8″ | 50 |
| DUTUX MHE 1414 | 1/4″ X 1/4″ | 50 |
| DUTUX MHE 14516 | 1/4″ X 5/16″ | 50 |
| DUTUX MHE 1438 | 1/4″ X 3/8″ | 50 |
| DUTUX MHE 1412 | 1/4″ X 1/2″ | 25 |
| DUTUX MHE 3814 | 3/8″ X 1/4″ | 50 |
| DUTUX MHE 38516 | 3/8″ X 5/16″ | 50 |
| DUTUX MHE 3838 | 3/8″ X 3/8″ | 50 |
| DUTUX MHE 3812 | 3/8″ X 1/2″ | 25 |
| DUTUX MHE 1214 | 1/2″ X 1/4″ | 25 |
| DUTUX MHE 12516 | 1/2″ X 5/16″ | 25 |
| DUTUX MHE 1238 | 1/2″ X 3/8″ | 25 |
| DUTUX MHE 1212 | 1/2″ X 1/2″ | 25 |
Any customized thread or size as per customer provided specifications.
Female Hose Elbow Application / Usage / Specification :
Air conditioning, Hydraulic, Marine, Mechanical and Refrigeration
Female Hose Elbow Finishing & Coating :
Natural
Golden Finish
Silver Finish
Nickle Platted
Chrome Platted
Tin Plated
Any coating as per customer specifications
Female Hose Elbow OEM Service :
Yes
Our company provide you products in your customized design with your brand.
Female Hose Elbow Material :
Free Cutting Brass IS 319 Type (l)
Free Cutting Brass as per BS 249 Type (I)
Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc.
High Grade Free Cutting Brass.
Any Special Brass Material Composition as per customer’s requirement
Female Hose Elbow Special Features :
Made from forged brass to maximize strength and eliminate cracks
Tubing should be double flared in extreme applications to minimize flare thinning on over-tightening
Long dry seal pipe threads minimize leakage and provide more clearance for tightening flare nuts
Long nuts are recommended when vibration is a factor
Slight deviations will occur when full compliance fittings are not available
Tube fittings are make and brake, have good vibration resistance, economical, easy to assemble and are available in a wide variety
Heavy duty AC tube fittings generally conform to SAE, ASA and ARI standards for marine, hydraulic and refrigeration service.
Thread as per international Go and Not Go Gauge Standard.
Deep Groove for maximum Pull out Resistance.
Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass Flare Dead Nut.
High internal and external surfaces clean.
High dimensional accuracy.
High heat transfer efficiency.
Easy welding.
Corrosion resistance.
Formability use long life.
Leakage-proof
Female Hose Elbow Packing Details :
Bag Packging
Box Packing
Innear Plastic Packing
Carton Packaging
Woodan Carton Packing
