The Connector Male Elbow Assembly is a comprehensive and reliable fitting solution designed to connect two pipes or tubes at a 90-degree angle, while ensuring a secure, leak-proof connection. Featuring a male threaded design, this assembly is built to work with female BSP (British Standard Pipe) threaded components for easy installation and compatibility. Constructed from high-quality materials such as brass, stainless steel, or other corrosion-resistant alloys, the assembly provides durability and strength, making it ideal for use in fluid, gas, and pneumatic systems. The Connector Male Elbow Assembly is widely used in industries including plumbing, HVAC, automotive, and fluid handling, offering a space-efficient and robust solution for changing pipe direction in tight spaces. It ensures long-lasting performance, reliable operation, and ease of maintenance.
| Brand Name | dutux |
| Metal | Brass / Copper Alloy |
| MOQ | 1000 Pieces |
| Lead Time | 3 Working Days |
| Available Price | EX – Work FOB – Free On Board C&F – Cost And Freight CIF – Cost, Insurance, and Freight |
Connector Male Elbow Assembly Application / Usage / Specification
Air conditioning, Hydraulic, Marine, Mechanical and Refrigeration
Connector Male Elbow Assembly Finishing & Coating
Natural
Golden Finish
Silver Finish
Nickle Platted
Chrome Platted
Tin Plated
Any coating as per customer specifications
Connector Male Elbow Assembly OEM Service
Yes
Our company provide you products in your customized design with your brand.
Connector Male Elbow Assembly Material
Free Cutting Brass IS 319 Type (l)
Free Cutting Brass as per BS 249 Type (I)
Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc.
High Grade Free Cutting Brass.
Any Special Brass Material Composition as per customer’s requirement
Connector Male Elbow Assembly Special Features
Made from forged brass to maximize strength and eliminate cracks
Tubing should be double flared in extreme applications to minimize flare thinning on over-tightening
Long dry seal pipe threads minimize leakage and provide more clearance for tightening flare nuts
Long nuts are recommended when vibration is a factor
Slight deviations will occur when full compliance fittings are not available
Tube fittings are make and brake, have good vibration resistance, economical, easy to assemble and are available in a wide variety
Heavy duty AC tube fittings generally conform to SAE, ASA and ARI standards for marine, hydraulic and refrigeration service.
Thread as per international Go and Not Go Gauge Standard.
Deep Groove for maximum Pull out Resistance.
Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass Flare Dead Nut.
High internal and external surfaces clean.
High dimensional accuracy.
High heat transfer efficiency.
Easy welding.
Corrosion resistance.
Formability use long life.
Leakage-proof
Connector Male Elbow Assembly Packing Details
Bag Packging
Box Packing
Innear Plastic Packing
Carton Packaging
Wooden Carton Packing
