Brass Split Valve L / Bend Size:
| Part No. | Size |
|---|---|
| DUTUX BSVB 14 | 1/4″ |
| DUTUX BSVB 38 | 3/8″ |
| DUTUX BSVB 12 | 1/2″ |
| DUTUX BSVB 58 | 5/8″ |
Any customized thread or size as per customer provided specifications.
Brass Split Valve L / Bend Application / Usage / Specification :
Air conditioning
Brass Split Valve L Rod :
Casting / Extrusion /Forged
Applicable for all common HFC, HFO refrigerants1) such as:
R134a, R404A, R407C, R410A, R507A, R407A, R407F,R448A, R449A, R452A, R450A/R513A2
Ambient temperature min./max.: -30°C / +55°C
Medium temperature TS min./max.: -30 °C / +120°C
Max. operating pressure PS: 4,5 MPa (45 bar)
Installation position: Preferably liquid and suction line
Brass Split Valve L / Bend Finishing & Coating :
Natural
Golden Finish
Silver Finish
Nickle Platted
Chrome Platted
Tin Plated
Any coating as per customer specifications
Brass Split Valve L / Bend OEM Service :
Yes
Our company provide you products in your customized design with your brand.
Brass Split Valve L / Bend Material :
Free Cutting Brass IS 319 Type (l)
Free Cutting Brass as per BS 249 Type (I)
Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc.
High Grade Free Cutting Brass.
Any Special Brass Material Composition as per customer’s requirement
Brass Split Valve L / Bend Special Features :
Thread as per international Go and Not Go Gauge Standard.
Deep Groove for maximum Pull out Resistance.
Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass split valve.
High internal and external surfaces clean.
High dimensional accuracy.
High heat transfer efficiency.
Easy welding.
Corrosion resistance.
Formability use long life.
Leakage-proof
Brass Split Valve L / Bend Packing Details :
Bag Packging
Box Packing
Innear Plastic Packing
Carton Packaging
Wooden Carton Packing
